| 12 | 40 | 1.1/2 | EC |
|---|---|---|---|
| Spherical Outside Diameter - Short Inner Ring | Basic Group | 1.1/2 Inch Shaft Diameter | Eccentric Collar Lock - Short Inner Ring |
| Dimensions (mm) | ||||
|---|---|---|---|---|
| Shaft Diameter | D | C | B2 | s1 |
| 1.1/2 | 80 | 18 | 43.73 | 11.03 |
| Dimensions (mm) | Dynamic Load (N) | Static Load (N) | Max Speed (rpm) | Weight (Kg) | |
|---|---|---|---|---|---|
| d2 | r | ||||
| 60.3 | 1 | 32500 | 19900 | 4000 | 0.73 |
