| 12 | 35 | 1.3/8 | EC |
|---|---|---|---|
| Spherical Outside Diameter - Short Inner Ring | Basic Group | 1.3/8 Inch Shaft Diameter | Eccentric Collar Lock - Short Inner Ring |
| Dimensions (mm) | ||||
|---|---|---|---|---|
| Shaft Diameter | D | C | B2 | s1 |
| 1.3/8 | 72 | 17 | 38.93 | 9.53 |
| Dimensions (mm) | Dynamic Load (N) | Static Load (N) | Max Speed (rpm) | Weight (Kg) | |
|---|---|---|---|---|---|
| d2 | r | ||||
| 55.6 | 1 | 25700 | 15300 | 4500 | 0.58 |
