| 12 | 30 | 30 | EC |
|---|---|---|---|
| Spherical Outside Diameter - Short Inner Ring | Basic Group | 30mm Shaft Diameter | Eccentric Collar Lock - Short Inner Ring |
| Dimensions (mm) | ||||
|---|---|---|---|---|
| Shaft Diameter | D | C | B2 | s1 |
| 30 | 62 | 16 | 35.73 | 9.03 |
| Dimensions (mm) | Dynamic Load (N) | Static Load (N) | Max Speed (rpm) | Weight (Kg) | |
|---|---|---|---|---|---|
| d2 | r | ||||
| 44.5 | 1 | 19500 | 11300 | 5300 | 0.4 |
