| 10 | 55 | 2.3/16 | DECG |
|---|---|---|---|
| Spherical Outside Diameter | Basic Group | 2.3/16 Inch Shaft Diameter | Re-greaseable, Eccentric collar lock with extended inner ring. |
| Dimensions (mm) | |||||
|---|---|---|---|---|---|
| Shaft Diameter | D | C | B3 | s2 | |
| 2.3/16 | 100 | 21 | 71.42 | 27.84 | |
| Dimensions (mm) | Dynamic Load (N) | Static Load (N) | Max Speed (rpm) | Weight (Kg) | |
|---|---|---|---|---|---|
| d2 | r | ||||
| 76.2 | 1.5 | 43500 | 29200 | 3100 | 1.4 |
