| 10 | 40 | 35 | KG | H308 |
|---|---|---|---|---|
| Spherical Outside Diameter | Basic Group | 35mm Shaft Diameter | Re-greaseable, Taper Sleeve Lock | Sleeve Nut & Lock Washer |
| Dimensions (mm) | ||||||
|---|---|---|---|---|---|---|
| Sleeve Nut & Lock Washer | D | C | B4 | B5 | B6 | d |
| H308 | 80 | 18 | 22 | 36 | 10 | 40 |
| Dimensions (mm) | Dynamic Load (N) | Static Load (N) | Max Speed (rpm) | Weight (Kg) | ||
|---|---|---|---|---|---|---|
| d1 | d4 | r | ||||
| 52.4 | 58 | 1 | 32500 | 19900 | 4000 | 0.54 |
