| 10 | 40 | 1.1/2 | DECG |
|---|---|---|---|
| Spherical Outside Diameter | Basic Group | 1.1/2 Inch Shaft Diameter | Re-greaseable, Eccentric collar lock with extended inner ring. |
| Dimensions (mm) | |||||
|---|---|---|---|---|---|
| Shaft Diameter | D | C | B3 | s2 | |
| 1.1/2 | 80 | 18 | 56.33 | 21.43 | |
| Dimensions (mm) | Dynamic Load (N) | Static Load (N) | Max Speed (rpm) | Weight (Kg) | |
|---|---|---|---|---|---|
| d2 | r | ||||
| 60.3 | 1 | 32500 | 19900 | 4000 | 0.82 |
